To access the full version, please re-direct to this link.

To access the single pair version, please re-direct to this link.

Dashboard Super Risk Reward PanelMT5Demo is the demo version of Dashboard Super Risk Reward Panel MT5, which have full functionalities of the paid version, except

• only two support/resistance levels (Daily Pivot and Weekly Pivot) are available for RR ratio calculation
• Sell button is disabled

Features

• User is able to select support and resistance levels for RR ratio generating.
• Adjustable indicator panel position

Make sure completing the following action items to make this dashboard working.

important Action Items before Using Dashboard

1. For the first time loading Dashboard, it may take 3-5 minutes to download historical data. For subsequent loading, it only takes a few seconds.
2. Make sure you have all 28 symbols in Symbol window (if your broker offers 28 pairs).
3. To make your dashboard looks clear and neat, it’s better to apply the black template. Please refer to screenshot 5.

Input Parameters

• Use Pivot Support1
• Use pivot support for RR ratio calculation
• Same rule applied to the following 6 support/resistance levels.
• Use Pivot Resistance1
• Use Daily Pivot
• Use Weekly Pivot
• Use Monthly Pivot
• Use Previous Daily High
• Use Previous Daily Low
• SR Stop-Loss Buffer
• Magic Number
• Lot Size:
• Basket TP in $
• Basket SL in $
• Max Spread: once spread exceeds max spread, spread of that pair will be highlighted in red.
• Suffix: suffix string of your symbol. i.e.: your symbol is ‘EURUSDx’ instead of ‘EURUSD’, input ‘x’ in suffix cell, leave prefix cell blank
• Prefix: prefix string of your symbol
• X_axis:dashboard x position
• Y_axis: dashboard x position

Dashboard Objects

Please refer to screenshot 6 to 8.

1. Pair Tick Button: Click once to active the corresponding pair for trading. Click once more to de-active.
2. Spread column: show current spread of each pair.
3. SR Status Panel: indicates which Support/Resistance level is selected for RR ratio calculation
4. Upper Closest Column: cell is repainted to be green to indicate that this support/resistance level is the upper closest level
5. Lower Closest Column: cell is repainted to be red to indicate that this support/resistance level is the lower closest level
6. Up Column: indicate the distance between upper closest SR level to current price
7. Down Column: indicate the distance between Lower closest SR level to current price
8. Buy Button: place buy order with upper closest SR level as TP, and lower closest SR level as SL
9. Sell Button: place sell order with lower closest SR level as TP, and upper closest SR level as SL
10. Close Button: close all positions of corresponding pair
11. Buy Volume Column
12. Sell Volume Column
13. Symbol:
14. Profit Column
15. Profit Baskets: calculate the number of baskets hitting TP
16. Basket TP: Basket take profit
17. Basket Highest: the maximum profit that current basket ever reach
18. Loss Baskets: calculate the number of baskets hitting SL
19. Basket SL: Basket stop loss
20. Basket Lowest: the maximum loss that current basket ever reach
21. Current Basket Profit: Current basket profit
22. Close All: close all positions
23. Close Profit: close all positions in profit
24. Close Loss: close all positions in loss

If you have any customized request and/or suggestion, please feedback to me.
